18 LFA 1400 V2

Name: 18 LFA 1400 V2
Brand: POWERX PRO
Availability: InStock

The 18 LFA 1400 V2 is an elite 18-inch low-frequency transducer belonging to the acclaimed PRO SERIES. Designed to serve as a premier acoustic engine, this speaker driver provides the perfect backbone for demanding live sound subwoofers and permanent stage monitoring setups.

Prioritizing immense acoustic output, it handles a continuous 1400 AES Watts with a peak maximum power capability of 2800 Watts. Supported by a strong sensitivity of 98 dB (1W/1M), this transducer offers the dynamic headroom required to push serious overall loudness without sacrificing clarity at peak performance levels.

Driver technology is anchored by an oversized 101.6 mm (4.5-inch) voice coil paired with a heavy-duty Ferrite magnet structure. Utilizing a high-quality paper cone, the internal acoustics are optimized to deliver phase-accurate, hard-hitting dispersion that effectively covers large venue spaces.

Engineered for precise low-end fidelity, it features a focused frequency response of 38 Hz to 200 Hz alongside a resonant frequency (Fs) of 38 Hz. This exceptionally tight sonic character ensures punchy, transparent bass reproduction and highly efficient crossover integration for pure acoustic delivery.

Built to withstand heavy touring demands, the unit features an overall diameter of 460 mm and a mounting depth of 241 mm. Weighing in at 16.7 Kg with a standard 8 ohms nominal impedance, it is a highly reliable component ready for integration into rugged plywood cabinets and professional rigging hardware.

More information

18 LFA 1400 V2 — Key Features
1400 W AES Power Handling

The 18 LFA 1400 V2 is engineered for extreme professional audio applications, delivering an impressive 1400 W AES continuous power handling and up to 2800 W program power. This substantial power capacity provides the headroom required for high-output subwoofer and sound reinforcement systems.

High-Output 18-Inch LF Transducer

Designed as an 18-inch professional low-frequency transducer, the 18 LFA 1400 V2 is built to serve as a powerful acoustic engine for demanding live sound, touring subwoofers, stage systems, and permanent installations.

4.5-Inch Voice Coil

The oversized 101.6 mm (4.5-inch) voice coil is designed for high-power operation and reliable thermal performance, allowing the driver to maintain consistent output during demanding extended use.

Robust Ferrite Magnet Structure

A heavy-duty Ferrite magnet structure provides the magnetic force required for powerful and controlled cone movement. This robust motor assembly is engineered for reliable operation in professional sound reinforcement environments.

Paper Cone Construction

The high-quality paper cone is designed to provide responsive low-frequency reproduction with a natural acoustic character. Its construction supports controlled cone movement and powerful bass output.

Powerful Low-Frequency Response

The 18 LFA 1400 V2 is engineered for low-frequency applications, with a stated frequency response of 30 Hz – 1 kHz. The supplied product description further specifies a focused operating range of 38 Hz – 200 Hz, making it particularly suited to powerful subwoofer and bass applications.

98 dB Sensitivity

With 98 dB sensitivity (1W/1m), the driver efficiently converts amplifier power into acoustic output, helping professional systems achieve high SPL while retaining useful dynamic headroom.

Deep & Controlled Bass

With an Fs of 38 Hz, the driver is designed to produce deep, punchy, and controlled low-frequency performance. Its low-frequency characteristics make it well suited for applications where strong bass impact and efficient subwoofer integration are essential.

Professional, Road-Ready Construction

Built for demanding professional use, the driver features an overall diameter of 460 mm and 241 mm mounting depth, allowing it to be integrated into rugged, purpose-built speaker cabinets and professional subwoofer enclosures.

Built for Demanding Applications

With a net weight of 16.7 kg and an 8-ohm nominal impedance, the 18 LFA 1400 V2 provides a robust combination of power handling, efficiency, and system compatibility.

Technical specification

Following is the technical specification of 18 LFA 1400 V2 :-
1400 AES Watt/ 2800 Program Power
101.6mm (4.5 inch voice coil)
30 Hz to 1 KHz Frequency response
Ferrite magnet structure
Paper Cone
